TEFC
Induction Motor, Foot Mount
Foot
Mount (B3) Flange
Mount (B5)
|
|
Rated Power |
Frame |
|
2-pole |
4-pole |
6-pole |
8-pole |
|
KW |
HP |
KW |
HP |
KW |
HP |
KW |
HP |
60Hz
|
50Hz
|
|
0.75KW |
1HP |
0.4KW |
1/2HP |
0.2KW |
1/4HP |
0.2KW |
1/4HP |
80 |
71
|
|
|
|
0.75KW |
1HP |
0.4KW |
1/2HP |
|
|
80 |
80
|
|
1.5KW |
2HP |
1.5KW |
2HP |
0.75KW |
1HP |
0.4KW |
1/2HP |
90L |
90L
|
|
2.2KW |
3HP |
|
|
|
|
|
|
90L |
90L
|
|
|
|
2.2KW |
3HP |
1.5KW |
2HP |
0.75KW |
1HP |
100L |
100L
|
|
3.7KW |
5HP |
3.7KW |
5HP |
2.2KW |
3HP |
1.5KW |
2HP |
112M |
112M
|
|
5.5KW |
7.5HP |
5.5KW |
7.5HP |
3.7KW |
5HP |
2.2KW |
3HP |
132S |
132S
|
|
7.5KW |
10HP |
|
|
|
|
|
|
132S |
132S
|
|
|
|
7.5KW |
10HP |
5.5KW |
7.5HP |
3.7KW |
5HP |
132M |
132M
|
|
11KW |
15HP |
11KW |
15HP |
7.5KW |
10HP |
5.5KW |
7.5HP |
160M |
160M
|
|
15KW |
20HP |
|
|
|
|
|
|
160M |
160M
|
|
18.5KW |
25HP |
15KW |
20HP |
11KW |
15HP |
7.5KW |
10HP |
160L |
160L
|
|
22KW |
30HP |
18.5KW |
25HP |
15KW |
20HP |
11KW |
15HP |
180M |
180M
|
|
|
|
22KW |
30HP |
|
|
|
|
180M |
180L
|
|
30KW |
40HP |
30KW |
40HP |
18.5KW |
25HP |
15KW |
20HP |
180L |
200L
|
|
|
|
|
|
22KW |
30HP |
|
|
180L |
200L
|
|
37KW |
50HP |
37KW |
50HP |
30KW |
40HP |
18.5KW |
25HP |
200L |
225S
|
|
45KW |
60HP |
45KW |
60HP |
37KW |
50HP |
22KW |
30HP |
200L |
225M
|
|
55KW |
75HP |
55KW |
75HP |
45KW |
60HP |
30KW |
40HP |
225M |
250S
|
|
75KW |
100HP |
75KW |
100HP |
55KW |
75HP |
37KW |
50HP |
250S |
250M
|
|
90KW |
120HP |
90KW |
120HP |
75KW |
100HP |
45KW |
60HP |
250M |
280S
|
|
110KW |
150HP |
110KW |
150HP |
90KW |
120HP |
55KW |
75HP |
280S |
280M
|
|
132KW |
175HP |
132KW |
175HP |
110KW |
150HP |
75KW |
100HP |
280M |
315S
|
|
|
|
160KW |
215HP |
132KW |
175HP |
90KW |
120HP |
280LL |
315L
|
|
|
|
200KW |
270HP |
160KW |
215HP |
110KW |
150HP |
280LL |
315L
|
|
|
General
Specifications |
|
Mount |
Foot Mount
- Horizontal(B3) |
|
Phase |
3 |
|
Rated Voltage |
220,
380, 400, 440, 220/380, 220/440, 415, 460V
|
|
Frequency |
50, 60Hz |
|
Pole |
2,
4, 6, 8 |
|
Enclosure & Cooling |
TEFC
(Totally Enclosed, Fan-Cooled), IP54, IP55
|
|
Efficiency |
High
(IE2), Premium (IE3) |
|
Duty |
Continuous
(S1) |
|
Insulation Class |
F |
|
Service Factor |
1.15 |
|
Option |
Explosion Proof
(Ex e II T3) |
|
Ambient Temperature |
-20°C
~ +40°C |
|
Ambient Humidity |
Less than 80% |
|
|
