LS Metasol ABS1003b Molded Case Circuit Breaker (MCCB)

1000AF

AF		1000AF
Type		S-Type	L-Type
Model and Pole	3-pole	ABS1003b	ABL1003b
Model and Pole	4-pole	ABS1004b	ABL1004b
Rated current, In	A	1000
Rated operational voltage, Ue	AC(V)	600
Rated insulation voltage, Ui	V	690
Rated impulse withstand voltage, Uimp	kV	6
Rated short-circuit breaking capacity (Icu) kA (Sym), IEC 60947-2 AC	480/500V	50	75
	415/460V	65	85
	380V	65	85
	220/250V	100	125
Ics=%×Icu		50
