Item

Specifications

Nominal Impulse Discharge Current

20kA / mode (8 x 20 uS)

60kA / Total (8 x 20 uS)

Response Time

1 nsec or less

Internal Serial Resistance

Approx 5 Ohms, 2 wire including return

Discharge Voltage

13V ~ 15V or more

Maximum Line Voltage

14V DC

Maximum Load Current

200mA

Rated Voltage

10.5V DC

Current Leakage

100㎂ or less

Ambient Temperature and Humidity

-40℃ ~ 80℃, 90% RH

Elements

UL Approved Parts

Featured Function

Automatic Return after Surge Inflow

Case Material & Color

Flame-resistant Resin / Black

Mounting

Plug-in Type, Base & Body Separable

Weight

110g

Dimensions

22(W) x 75(H) x 85(D) mm
