Input
Signals
Input
Signal Types
|
Type |
Range |
Symbol |
|
mA |
DC 4~20mA |
20MA |
|
2-wire |
DC
24V/4~20mA |
20MA |
|
SQT |
DC 4~20mA |
20MA |
Ordering
Example
|
Ordering
Code |
SCONI-2100-1NY
SCN-210-1NY
|
|
Input
|
Various Input Signals
Ex. DC 4 ~ 20mA
(also with 24V Power) |
|
1 |
Output-1
|
DC 0 ~ 5V |
|
N |
Output-2
|
None |
|
Y |
Power
Supply
|
DC 24V |
|
Ordering
Code |
SCONI-2100-2NY
SCN-210-2NY
|
|
Input
|
Various Input Signals
Ex. DC 4 ~ 20mA
(also with 24V Power) |
|
2 |
Output-1
|
DC 0 ~ 10V |
|
N |
Output-2
|
None |
|
Y |
Power
Supply
|
DC 24V |
|
Ordering
Code |
SCONI-2100-55X
SCN-210-55X
|
|
Input
|
Various Input Signals
Ex. DC 4 ~ 20mA
(also with 24V Power) |
|
5 |
Output-1
|
DC 4 ~ 20mA |
|
5 |
Output-2
|
DC 4 ~ 20mA |
|
X |
Power
Supply
|
AC 85~264V
(50~60Hz) |
|
Output-1
Signals
|
1 |
DC 0 ~ 5V |
|
2 |
DC 0 ~ 10V |
|
3 |
DC 1 ~ 5V |
|
4 |
DC 0 ~ 20mA |
|
5 |
DC 4 ~ 20mA |
|
6 |
DC 1 ~ 5mA |
|
R |
Other |
Output-2
Signals
|
1 |
DC 0 ~ 5V |
|
2 |
DC 0 ~ 10V |
|
3 |
DC 1 ~ 5V |
|
4 |
DC 0 ~ 20mA |
|
5 |
DC 4 ~ 20mA |
|
6 |
DC 1 ~ 5mA |
|
R |
Other |
Power
Supply
|
X |
AC 85~264V
(50~60Hz) |
|
Y |
DC 24V
(Option) |
|
