Input
Signals
Input
Signal Types
|
Type |
Range |
Symbol |
|
PT |
Pt100Ω |
-199.9 ~
800.0°C |
D-PT |
|
JPt100Ω |
-199.9 ~
500.0°C |
J-PT |
|
PMC |
0~100kΩ |
0 ~ 100 kΩ |
PMC |
Ordering
Example
|
Ordering
Code |
SCONI-2300-5NX
SCN-230-5NX
|
|
Input
|
Various Input Signals
Ex. 0 ~ 5kΩ
(3-wire
Potentiometer)
|
|
5 |
Output-1
|
DC 4 ~ 20mA |
|
N |
Output-2
|
None |
|
Y |
Power
Supply
|
AC 85~264V
(50~60Hz) |
|
Ordering
Code |
SCONI-2300-5NY
SCN-230-5NY
|
|
Input
|
Various Input Signals
Ex. 0 ~ 5kΩ
(3-wire
Potentiometer)
|
|
5 |
Output-1
|
DC 4 ~ 20mA |
|
N |
Output-2
|
None |
|
Y |
Power
Supply
|
DC 24V |
|
Ordering
Code |
SCONI-2300-52Y
SCN-230-52Y
|
|
Input
|
Various Input Signals
Ex. 0 ~ 5kΩ
(3-wire
Potentiometer)
|
|
5 |
Output-1
|
DC 4 ~ 20mA |
|
2 |
Output-2
|
DC 0 ~ 10V |
|
Y |
Power
Supply
|
DC 24V |
|
Ordering
Code |
SCONI-2300-22Y
SCN-230-22Y
|
|
Input
|
Various Input Signals
Ex. 0 ~ 5kΩ
(3-wire
Potentiometer)
|
|
2 |
Output-1
|
DC 0 ~ 10V |
|
2 |
Output-2
|
DC 0 ~ 10V |
|
Y |
Power
Supply
|
DC 24V |
|
Output-1
Signals
|
1 |
DC 0 ~ 5V |
|
2 |
DC 0 ~ 10V |
|
3 |
DC 1 ~ 5V |
|
4 |
DC 0 ~ 20mA |
|
5 |
DC 4 ~ 20mA |
|
6 |
DC 1 ~ 5mA |
|
R |
Other |
Output-2
Signals
|
1 |
DC 0 ~ 5V |
|
2 |
DC 0 ~ 10V |
|
3 |
DC 1 ~ 5V |
|
4 |
DC 0 ~ 20mA |
|
5 |
DC 4 ~ 20mA |
|
6 |
DC 1 ~ 5mA |
|
R |
Other |
Power
Supply
|
X |
AC 85~264V
(50~60Hz) |
|
Y |
DC 24V
(Option) |
|
