Input
Signals
|
Multi |
A
|
12V
SUP / Voltage Pulse
|
|
B
|
12V
SUP / Dry Contact
|
|
C
|
12V
SUP / Open Collector
|
Frequency
Range for Code
|
Range Code |
Frequency
Range |
|
10 H |
0.000 ~ 9.999Hz |
|
100 H |
00.00 ~ 99.99Hz |
|
1 KH |
000.0 ~ 999.9Hz |
|
20 KH |
00.00 ~ 20.00 KHz |
|
100 KH |
000.0 ~ 100.0 KHz |
|
Max 50 KHz in case of
Open Collector |
Ordering
Example
|
Ordering
Code |
SCONI-2400-27Y
|
|
C
|
Input
|
Various Pulse Signals
Ex.
12V
SUP
/ Open Collector
|
|
2 |
Output-1
|
DC 0 ~ 10V |
|
7 |
Output-2
|
Open
Collector |
|
Y |
Power
Supply
|
DC 24V |
|
Ordering
Code |
SCONI-2400-2NX
SCN-240-C2NX
|
|
C
|
Input
|
Various Pulse Signals
Ex.
12V
SUP
/ Open Collector
|
|
2 |
Output-1
|
DC 0 ~ 10V |
|
N |
Output-2
|
None |
|
X |
Power
Supply
|
AC 85~264V
(50~60Hz) |
|
Ordering
Code |
SCONI-2400-2NY
SCN-240-C2NY
|
|
C
|
Input
|
Various Pulse Signals
Ex.
12V
SUP
/ Open Collector
|
|
2 |
Output-1
|
DC 0 ~ 10V |
|
N |
Output-2
|
None |
|
Y |
Power
Supply
|
DC 24V |
|
Ordering
Code |
SCONI-2400-5NX
SCN-240-C5NX
|
|
C
|
Input
|
Various Pulse Signals
Ex.
12V
SUP
/ Open Collector
|
|
5 |
Output-1
|
DC 4 ~ 20mA |
|
N |
Output-2
|
None |
|
X |
Power
Supply
|
AC 85~264V
(50~60Hz) |
|
Ordering
Code |
SCONI-2400-5NY
SCN-240-C5NY
|
|
C
|
Input
|
Various Pulse Signals
Ex.
12V
SUP
/ Open Collector
|
|
5 |
Output-1
|
DC 4 ~ 20mA |
|
N |
Output-2
|
None |
|
Y |
Power
Supply
|
DC 24V |
|
Output-1
Signals
|
1 |
DC 0 ~ 5V |
|
2 |
DC 0 ~ 10V |
|
3 |
DC 1 ~ 5V |
|
4 |
DC 0 ~ 20mA |
|
5 |
DC 4 ~ 20mA |
|
6 |
DC 1 ~ 5mA |
|
R |
Other |
Output-2
Signals
|
1 |
DC 0 ~ 5V |
|
2 |
DC 0 ~ 10V |
|
3 |
DC 1 ~ 5V |
|
4 |
DC 0 ~ 20mA |
|
5 |
DC 4 ~ 20mA |
|
6 |
DC 1 ~ 5mA |
|
7 |
Open
Collector |
|
R |
Other |
Power
Supply
|
X |
AC 85~264V
(50~60Hz) |
|
Y |
DC 24V
(Option) |
|
