Multi
Input
Signals
|
T/C
(K, R, B, S, E, J, T)
|
|
4~20mA
DC (Common for 2-wire)
0~20mA
DC
|
|
0~10V
DC, -10V~10V DC
0~5V
DC, 1~5V DC
|
|
Pt
100Ω
|
Input
Signal Range
|
Type
|
Range
|
Symbol
|
|
T/C
|
B(PR)
|
0
~ 1800℃
|
TC-B
|
|
R(RR)
|
0
~ 1750℃
|
TC-R
|
|
S(PR)
|
0
~ 1750℃
|
TC-S
|
|
K(CA)
|
-200
~ 1350℃
|
TC-K
|
|
E(CRC)
|
-199.9~700.0℃
|
TC-E
|
|
J(IC)
|
-199.9~800.0℃
|
TC-J
|
|
T(CC)
|
-199.9~400.0℃
|
TC-T
|
|
DC
Volt
|
Volt
|
0
~ 10V DC
|
10
V
|
|
Volt
|
1
~ 5V DC
|
|
Volt
|
-10
~ 10V
|
|
DC
mA
|
mA
|
4
~ 20 mA
|
MA
|
|
RTD
|
Pt100Ω
|
-199.9~700.0℃
|
D-PT
|
Ordering
Example
|
Ordering
Code |
SCN-8400-5NX
|
|
8400
|
Input
|
Various Input Signals
Ex. DC 4 ~ 20mA
(also with 24V Power) |
|
5 |
Output-1
|
DC
4 ~ 20mA
|
|
N |
Output-2
|
None
|
|
X |
Power
Supply
|
AC
85~264V / 50~60Hz
|
|
Ordering
Code |
SCN-8400-5NY
|
|
8400
|
Input
|
Various Input Signals
Ex. DC 4 ~ 20mA
(also with 24V Power)
or
Pt100
Temperature
Sensor
|
|
5 |
Output-1
|
DC
4 ~ 20mA
|
|
N |
Output-2
|
None
|
|
Y |
Power
Supply
|
DC
24V
|
|
Ordering
Code |
SCN-8400-55X
|
|
8400
|
Input
|
Various Input Signals
Ex. DC 4 ~ 20mA
(also with 24V Power) |
|
5 |
Output-1
|
DC
4 ~ 20mA
|
|
5 |
Output-2
|
DC
4 ~ 20mA
|
|
X |
Power
Supply
|
AC
85~264V / 50~60Hz
|
|
Ordering
Code |
SCN-8400-55Y
|
|
8400
|
Input
|
Various Input Signals
Ex. DC 4 ~ 20mA
(also with 24V Power)
or
Pt100
Temperature
Sensor
|
|
5 |
Output-1
|
DC
4 ~ 20mA
|
|
5 |
Output-2
|
DC
4 ~ 20mA
|
|
Y |
Power
Supply
|
DC
24V
|
|
Output-1
Signals
|
1
|
DC
0 ~ 5V
|
|
2
|
DC
0 ~ 10V
|
|
3
|
DC
1 ~ 5V
|
|
4
|
DC
0 ~ 20mA
|
|
5
|
DC
4 ~ 20mA
|
|
R
|
Other
|
Output-2
Signals
|
1
|
DC
0 ~ 5V
|
|
2
|
DC
0 ~ 10V
|
|
3
|
DC
1 ~ 5V
|
|
4
|
DC
0 ~ 20mA
|
|
5
|
DC
4 ~ 20mA
|
|
6
|
ALARM
2
|
|
7
|
ALARM
4
|
|
R
|
Other
|
Power
Supply
|
X
|
AC
85~264V / 50~60Hz
|
|
Y
|
DC
24V (Option)
|
|
