Input
Signals
|
A |
Voltage
Pulse / 3-wire |
|
B |
Current
Pulse |
|
C |
Voltage
Pulse / 2-wire |
|
D |
Open
Collector |
|
E |
Dry Contact |
|
R |
Other |
|
Specify
Frequency Range on
Order
|
Input
Specifications
|
Input |
Specification |
|
Frequency |
40 kHz |
|
Duty Ratio |
20 ~ 80% |
|
Sensor |
12V / 4mA |
Output
Specifications
|
Output |
Load Resistance |
Impedance |
|
0 ~
100mV |
1kΩ or
more |
100Ω or less |
|
0 ~ 5V |
2kΩ or
more |
0.1Ω or less |
|
0 ~ 10V |
4kΩ or
more |
|
0 ~ 1mA |
0 ~ 15kΩ |
5MΩ
or more |
|
4 ~ 20mA |
0 ~ 750Ω |
Ordering
Example
|
Ordering
Code |
SCN-FDC-C8NX
|
|
C
|
Input
|
Voltage
Pulse / 2-wire
|
|
8 |
Output-1
|
DC 4 ~ 20mA |
|
N |
Output-2
|
None |
|
X |
Power
Supply
|
AC
110V/220V
|
|
Ordering
Code |
SCONI-FDC-D8NY
|
|
D
|
Input
|
12VSup
/ Open
Collector
|
|
8 |
Output-1
|
DC 4 ~ 20mA |
|
N |
Output-2
|
None |
|
Y |
Power
Supply
|
DC
24V
|
|
Output-1
Signals
|
1
|
DC
0 ~ 50mV
|
|
2
|
DC
0 ~ 100mV
|
|
3
|
DC
0 ~ 5V
|
|
4
|
DC
0 ~ 10V
|
|
5
|
DC
1 ~ 5V
|
|
6
|
DC
0 ~ 1mA
|
|
7
|
DC
0 ~ 20mA
|
|
8
|
DC
4 ~ 20mA
|
|
R
|
Other
|
Output-2
Signals
|
1
|
DC
0 ~ 50mV
|
|
2
|
DC
0 ~ 100mV
|
|
3
|
DC
0 ~ 5V
|
|
4
|
DC
0 ~ 10V
|
|
5
|
DC
1 ~ 5V
|
|
6
|
DC
0 ~ 1mA
|
|
7
|
DC
0 ~ 20mA
|
|
8
|
DC
4 ~ 20mA
|
|
R
|
Other
|
Power
Supply
|
X
|
AC
110V/220V
|
|
Y
|
DC
24V (Option)
|
|
