Multiprocessors, Dual Cylinder




Features

Manufactured by compact type against a large opening width and the weight is reduced but the operating efficiency is now maximized by strong power and fast motion.

The cylinder supplemented existing equipment`s demerits demonstrates the dynamic power and superior durability and save the maintenance and repair costs with a fast motion. It maximized the operating efficiency (applied cylinder protection system).

The jaw made by durable material and heat treatment is not only light but also prevent inner abrasion and lengthen the life-span.

All the injected parts of the grease are finished by special sealing treatment and the grease can be injected smoothly and minimized the abrasion of the pin and bushing.

The rotating area is treated as a ring gear to save the maintenance cost sharply and possible to use without oil pressure line having by special break system.


Models & Specifications

Model

MS20-IIR

MD20-IIR

MP20-IIR

MS30-IIR

MD30-IIR

MP30-IIR

Weight, kg

1760

1760

1760

2800

2800

2800

Opening Width, mm

522

915

890

603

1026

968

Operating Pressure, kg/cm2

300

300

300

320

320

320

Suitable Excavator, ton

18 ~ 26

18 ~ 26

18 ~ 26

28 ~ 32

28 ~ 32

28 ~ 32
