Max Voltage : 3.6~7.2kV
For Indoor
Single Phase
Over Voltage Factor : 1.2Vn Cont., 1.9Vn/30sec (Option : 1.9Vn/8hr)
Specifications
Standard
KS C 1706
JEC 1201
IEC 61869-3
Max Voltage
7.2kV
6.9kV
Primary Voltage
6600/√3 V
Secondary Voltage
110/√3 V or 190/√3 V
Insulation Level
7.2 / 22 / 60kV
6.9 / 22 / 60kV
7.2 / 20 / 60kV
Over Voltage Factor
-
1.1Vn Cont., 1.9Vn/30min
1.2Vn Cont., 1.9Vn/30sec
Frequency
60Hz (option : 50Hz)
