HES
Pump
Models
|
|
Model |
Suc
(mm)
|
Dis
(mm)
|
Motor |
|
KW |
Frame,
Pole |
|
HES32-125 |
50 |
32 |
0.75 |
80,
4P |
|
50 |
32 |
1.5 |
90L,
4P |
|
50 |
32 |
2.2 |
100L,
4P |
|
HES32-160 |
50 |
32 |
0.75 |
80,
4P |
|
50 |
32 |
1.5 |
90L,
4P |
|
HES32-200 |
50 |
32 |
0.75 |
80,
4P |
|
50 |
32 |
1.5 |
90L,
4P |
|
HES32-250 |
50 |
32 |
2.2 |
100L,
4P |
|
50 |
32 |
3.7 |
112M,
4P |
|
HES40-125 |
65 |
40 |
0.75 |
80,
4P |
|
65 |
40 |
1.5 |
90L,
4P |
|
HES40-160 |
65 |
40 |
1.5 |
90L,
4P |
|
65 |
40 |
2.2 |
100L,
4P |
|
HES40-200 |
65 |
40 |
1.5 |
90L,
4P |
|
65 |
40 |
2.2 |
100L,
4P |
|
HES40-250 |
65 |
40 |
2.2 |
100L,
4P |
|
65 |
40 |
3.7 |
112M,
4P |
|
65 |
40 |
5.5 |
132S,
4P |
|
HES40-315 |
65 |
40 |
5.5 |
132S,
4P |
|
65 |
40 |
7.5 |
132M,
4P |
|
HES50-125 |
65 |
50 |
1.5 |
90L,
4P |
|
HES50-160 |
65 |
50 |
1.5 |
90L,
4P |
|
65 |
50 |
2.2 |
100L,
4P |
|
HES50-200 |
65 |
50 |
2.2 |
100L,
4P |
|
65 |
50 |
3.7 |
112M,
4P |
|
HES50-250 |
65 |
50 |
3.7 |
112M,
4P |
|
65 |
50 |
5.5 |
132S,
4P |
|
HES50-315 |
65 |
50 |
5.5 |
132S,
4P |
|
65 |
50 |
7.5 |
132M,
4P |
|
65 |
50 |
11 |
160M,
4P |
|
HES65-125 |
80 |
65 |
2.2 |
100L,
4P |
|
HES65-160 |
80 |
65 |
3.7 |
112M,
4P |
|
HES65-200 |
80 |
65 |
3.7 |
112M,
4P |
|
80 |
65 |
5.5 |
132S,
4P |
|
HES65-250 |
80 |
65 |
5.5 |
132S,
4P |
|
80 |
65 |
7.5 |
132M,
4P |
|
80 |
65 |
11 |
160M,
4P |
|
HES65-315 |
80 |
65 |
11 |
160M,
4P |
|
80 |
65 |
15 |
160L,
4P |
|
HES80-160 |
100 |
80 |
3.7 |
112M,
4P |
|
100 |
80 |
5.5 |
132S,
4P |
|
HES80-200 |
100 |
80 |
5.5 |
132S,
4P |
|
100 |
80 |
7.5 |
132M,
4P |
|
HES80-250 |
100 |
80 |
7.5 |
132M,
4P |
|
100 |
80 |
11 |
160M,
4P |
|
100 |
80 |
15 |
160L,
4P |
|
HES80-315 |
100 |
80 |
15 |
160L,
4P |
|
100 |
80 |
18.5/22 |
180M,
4P |
|
100 |
80 |
30 |
180L,
4P |
|
HES80-400 |
100 |
80 |
22 |
180M,
4P |
|
100 |
80 |
30 |
180L,
4P |
|
100 |
80 |
37/45 |
200L,
4P |
|
HES100-160 |
125 |
100 |
7.5 |
132M,
4P |
|
HES100-200 |
125 |
100 |
7.5 |
132M,
4P |
|
125 |
100 |
11 |
160M,
4P |
|
125 |
100 |
15 |
160L,
4P |
|
HES100-250 |
125 |
100 |
15 |
160L,
4P |
|
125 |
100 |
18.5 |
180M,
4P |
|
HES100-315 |
125 |
100 |
22 |
180M,
4P |
|
125 |
100 |
30 |
180L,
4P |
|
125 |
100 |
37/45 |
200L,
4P |
|
HES100-400 |
125 |
100 |
37/45 |
200L,
4P |
|
125 |
100 |
55 |
225S,
4P |
|
HES125-200 |
150 |
125 |
11 |
160M,
4P |
|
150 |
125 |
15 |
160L,
4P |
|
150 |
125 |
18.5/22 |
180M,
4P |
|
HES125-250 |
150 |
125 |
15 |
160L,
4P |
|
150 |
125 |
18.5/22 |
180M,
4P |
|
150 |
125 |
30 |
180L,
4P |
|
150 |
125 |
37/45 |
200L,
4P |
|
HES125-315 |
150 |
125 |
30 |
180L,
4P |
|
150 |
125 |
37/45 |
200L,
4P |
|
150 |
125 |
55 |
225S,
4P |
|
HES125-400 |
150 |
125 |
55 |
225S,
4P |
|
150 |
125 |
75 |
250S,
4P |
|
150 |
125 |
90 |
250M,
4P |
|
HES150-200 |
200 |
150 |
18.5/22 |
180M,
4P |
|
HES150-250 |
200 |
150 |
30 |
180L,
4P |
|
200 |
150 |
37/45 |
200L,
4P |
|
HES150-315 |
200 |
150 |
45 |
200L,
4P |
|
200 |
150 |
55 |
225S,
4P |
|
200 |
150 |
75 |
250S,
4P |
|
HES150-400 |
200 |
150 |
75 |
250S,
4P |
|
200 |
150 |
90 |
250M,
4P |
|
200 |
150 |
110 |
280S,
4P |
|
200 |
150 |
150 |
280L,
4P |
|
|
|
|
|
|
|
HES125-500 |
150 |
125 |
|
|
|
HES150-500 |
200 |
150 |
|
|
|
HES200-250 |
200 |
200 |
|
|
|
HES200-260 |
200 |
200 |
|
|
|
HES200-330 |
250 |
200 |
|
|
|
HES200-400 |
250 |
200 |
|
|
|
HES200-500 |
250 |
200 |
|
|
|
HES250-300 |
250 |
250 |
|
|
|
HES250-330 |
250 |
250 |
|
|
|
HES250-400 |
300 |
250 |
|
|
|
HES250-500 |
300 |
250 |
|
|
|
HES300-340 |
300 |
300 |
|
|
|
HES300-360 |
300 |
300 |
|
|
|
HES300-400 |
350 |
300 |
|
|
|
HES300-500 |
350 |
300 |
|
|
|
HES400-500 |
400 |
500 |
|
|
|
HES500-500 |
500 |
500 |
|
|
|
|
|
|
|
|
|
|
|
|
| Part No |
Part Name |
Material |
Option |
|
10101 |
Bearing Bracket |
GC200 |
- |
|
10102 |
Ball Bearing |
Steel |
- |
|
10103 |
Bearing Cover |
GC200 |
- |
|
10104 |
Hexagon Bolt |
SM25C |
- |
|
10105 |
Gasket |
Oil Paper |
- |
|
10106 |
Support Foot |
SS400 |
- |
|
10111 |
Thrower |
Rubber |
- |
|
10201 |
Shaft Sleeve |
SM45C |
STS304 |
|
10202 |
Shaft |
SM45C |
STS304 |
|
10203 |
Impeller Nut |
SM25C |
STS304 |
|
10205 |
Lock Washer |
STS304 |
SS400 |
|
10206 |
Coupling Key |
SM55C |
STS304 |
|
10207 |
Impeller Key |
SM55C |
STS304 |
|
20101 |
Volute Casing |
GC200 |
SSC13/GCD450 |
|
20102 |
Plug |
CAC406 |
STS304 |
|
| Part No |
Part Name |
Material |
Option |
|
20103 |
Plug |
CAC406 |
STS304 |
|
20201 |
Gasket |
Oil Paper |
Teflon |
|
20202 |
Hexagon Bolt |
SM45C |
STS304 |
|
301 |
Stuffing Housing |
GC200 |
SSC13/GCD450 |
|
302 |
Stud Bolt |
SM45C |
STS304 |
|
303 |
Hexagon Nut |
SM45C |
STS304 |
|
304 |
Mechanical Seal |
SiC/Carbon |
Customized |
|
305 |
Mechanical Seal Cover |
GC200 |
SSC13 |
|
401 |
Packing |
Carbon
Fiber |
Teflon/Graphite Impregnation |
|
402 |
Packing Gland |
GC200 |
Mechanical Seal |
|
403 |
Lantern Ring |
Acetal |
STS304 |
|
404 |
Packing Ring |
Acetal |
STS304 |
|
501 |
Impeller |
GC200 |
CAC406/SSC13 |
|
502 |
Casing Ring |
GC200 |
SSC13 |
|
503 |
Casing Ring |
GC200 |
SSC13 |
|
|
|
|
| Part No |
Part Name |
Material |
Option |
|
10101 |
Bearing Bracket |
GC200 |
- |
|
10102 |
Ball Bearing |
Steel |
- |
|
10103 |
Bearing Cover |
GC200 |
- |
|
10104 |
Hexagon Bolt |
SM25C |
- |
|
10105 |
Gasket |
Oil Paper |
- |
|
10106 |
Support Foot |
SS400 |
- |
|
10111 |
Thrower |
Rubber |
- |
|
10201 |
Shaft Sleeve |
SM45C |
STS304 |
|
10202 |
Shaft |
SM45C |
STS304 |
|
10203 |
Impeller Nut |
SM25C |
STS304 |
|
10206 |
Coupling Key |
SM55C |
STS304 |
|
10207 |
Impeller Key |
SM55C |
STS304 |
|
20101 |
Volute Casing |
GC200 |
SSC13/GCD450 |
|
20102 |
Plug |
CAC406 |
STS304 |
|
| Part No |
Part Name |
Material |
Option |
|
20103 |
Plug |
CAC406 |
STS304 |
|
20201 |
Gasket |
Oil Paper |
Teflon |
|
20202 |
Hexagon Bolt |
SM45C |
STS304 |
|
301 |
Stuffing Housing |
GC200 |
SSC13/GCD450 |
|
302 |
Stud Bolt |
SM45C |
STS304 |
|
303 |
Hexagon Nut |
SM45C |
STS304 |
|
304 |
Mechanical Seal |
SiC/Carbon |
Customized |
|
305 |
Mechanical Seal Cover |
GC200 |
SSC13 |
|
401 |
Packing |
Carbon
Fiber |
Teflon/Graphite Impregnation |
|
402 |
Packing Gland |
GC200 |
SSC13 |
|
403 |
Lantern Ring |
Acetal |
- |
|
501 |
Impeller |
GC200 |
CAC406/SSC13 |
|
502 |
Casing Ring |
GC200 |
CAC406/SSC13 |
|
503 |
Casing Ring |
GC200 |
CAC406/SSC13 |
|
|
|
