Model |
HiAS06 |
HiAS08 |
HiAS10 |
HiAS12 |
HiAS16 |
HiAS20 |
HiAS25 |
HiAS32 |
|
Rated
current (A) |
630 |
800 |
1,000 |
1,250 |
1,600 |
2,000 |
2,500 |
3,200 |
|
Rated
neutral phase current (A) |
630 |
800 |
1,000 |
1,250 |
1,600 |
2,000 |
2,500 |
3,200 |
|
Number of
poles |
3,
4 |
|
Rated
primary current of ACB
protection relay
[ICT] (A) |
160 |
160 |
160 |
160 |
160 |
1,000 |
1,000 |
1,000 |
|
320 |
320 |
320 |
320 |
320 |
1,600 |
1,600 |
1,600 |
|
630 |
630 |
630 |
630 |
630 |
2,000 |
2,000 |
2,000 |
|
|
800 |
800 |
800 |
800 |
|
2,500 |
2,500 |
|
|
|
1,000 |
1,000 |
1,000 |
|
|
3,200 |
|
|
|
|
1,250 |
1,250 |
|
|
|
|
|
|
|
|
1,600 |
|
|
|
|
Rated
insulation voltage (Ui) (V) |
AC1,000 |
|
Rated
operation voltage (Ue) (V) |
AC690 |
|
Rated breaking capacity
(kA sym) [lcu]
|
AC690V |
42 |
42 |
42 |
42 |
42 |
50 |
50 |
50 |
|
AC500V |
50 |
50 |
50 |
50 |
50 |
65 |
65 |
65 |
|
AC415V below |
50 |
50 |
50 |
50 |
50 |
65 |
65 |
65 |
|
AC600V |
42 |
42 |
42 |
42 |
42 |
50 |
50 |
50 |
|
AC500V below |
50 |
50 |
50 |
50 |
50 |
65 |
65 |
65 |
|
