Straight
Line Wire Drawing Machine
|
|
|
|
|
LSD
1200×8B
|
LSD
450×10B
|
LSD
560×9B + 450×3B
|
Straight
Line Wire Drawing Machine is used for straight drawing without any deflection through the machine
without theoretical limits as far as wire material and diameter are concerned.
Presently, this machine has remarkable drawing performance for low and high
carbon steel wire, stainless steel wire, special alloy steel wire,
nonferrous alloy steel wire, etc.
Features
- This
simple mechanical structure doesn¡¯t make trouble and easy maintenance.
- This machine has accurate performance and easy operation by using AC
or DC
motor.
- The high speed drawing can be achieved by high cooling effect by means of complete
wetting of the inside wall of the drums.
- This machine has no or hardly any trouble and is the most suitable for the
production of high quality wire.
- The main electrical equipment is housed in a cabinet and all required
operation can be controlled easily.
|
Model
|
LSD-250
|
LSD-300
|
LSD-350
|
LSD-400
|
LSD-450
|
LSD-560
|
LSD-600
|
LSD-700
|
LSD-750
|
LSD-900
|
LSD-1200
|
|
Diameter
of Capstan (mm, Ø)
|
250
|
300
|
350
|
400
|
450
|
560
|
600
|
700
|
750
|
900
|
1200
|
|
Inlet
Diameter of Wire (mm, Ø)
C=0.85%
|
2.0
|
2.8
|
3.5
|
4.0
|
5.0
|
5.5
|
6.5
|
8.0
|
10.0
|
12.7
|
16.0
|
18.0
|
|
Drawing
Speed (m/sec)
|
20~30
|
20~30
|
18~25
|
18~25
|
15~20
|
15~20
|
12~16
|
8~12
|
6~10
|
5~8
|
4~6
|
3~6
|
|
Drawing
Power (kW)
|
11~15
|
15~22
|
22~30
|
30~37
|
37~45
|
45~55
|
55~75
|
75~90
|
75~110
|
90~130
|
90~160
|
110~140
|
|
