High Torque Performance in Ultra Low
Speed Zone by Using Sensorless Vector Control |
|
- Hyundai’s advanced sensorless vector
control technology provides a motor with high torque performance in ultra low
speed zone
(Sensorless vector control: above
150% at 1Hz).
- In case of fast
acceleration/deceleration of motor, N700E series provides powerful torque
controllability without trip.
- Sensorless vector control technology
expands the range of controlling speed. |
|
Superb Speed Control Performance by
Improved Tuning Technology for Motors |
|
- Through technology of compensating the
motor time constant while motor tuning minimizes the speed change,
stable motor opeation can be achieved.
|
|
Intensified Protective Functions for
Safety while Running |
|
- Ground fault protection can prevent
accidents.
- Countermeasure for output's phase loss
protects motor while running. |
|
Built-in Regenerative Braking System |
|
- BRD is basically equipped with the
inverter so that the easy operation for acceleration/deceleration time is
achieved
without additional options.
- Driving performance of acceleration and
deceleration maximizes efficiency. |
|
Enhanced Flexibility for Various Loads |
|
- Provided various control function
(3-Wire, Local/Remote control etc.)
- Built in PID function uniformly
controls oil pressure and flow quantity without additional options.
- Improved torque characteristic, which
is reduced to the 1.7th power, perfectly fits with loads for fans and pumps.
- Optimized energy saving according to
the characteristics of loads is achieved. |
|
Various Inverter Display Functions |
|
- The operational status of the inverter
are displayed on the monitor so that an user can understand the condition of
the inverter.
- Cumulative hours of driving time and
the actual running time are displayed for easy maintenance. |
|
Convenient Maintenance and Repair |
|
- N700E is available to replace the fan
without separation.
- Fan on/off function increases fan's
durability and minimizes fan's noise. |
