HYUNDAI
HVF Vacuum Circuit Breaker
(VCB)
Ensuring excellent
switching capability and high quality with various advantages
|
- Retaining the high dielectric strength
with the interrupter of the high vacuum degree of 10-7mbar.
- Providing reliable mechanical
performance and long-life expectancy with rigid structure of motor-spring
energy stored mechanism.
- Having excellent breaking capability
with the special contact material designed by the advanced vacuum technology.
- Having rapid breaking time of 3 cycle.
- Certified by New IEC publication
62271-100 and other related standards by HYUNDAI in ISO9001/14001 and
OHSAS18001 certified facilities.
|
|
|
Rigid structure to prove high reliability
and long-life expectancy
|
- Wide 600 / 800mm switchgear available
with small size & light weight
- Mechanical endurance of 30,000
operations
|
|
Standard |
Rated voltage (kV) |
Rated short-circuit breaking current (kA) |
Rated current (A) |
|
IEC |
7.2-17.5kV |
25-50kA |
630-4,000A |
|
24/25.8kV |
12.5-31.5kA |
630-3,150A |
|
36/40.5kV |
25-31.5kA |
1,250-3,150A |
|
|
Ratings
|
Model |
HVF114 |
HVF115 |
HVF116 |
HVF117 |
HVF214 |
HVF215 |
HVF216 |
HVF217 |
| Standard |
IEC 62271-100 |
| Rated voltage (kV) |
7.2 |
12 |
| Frequency (Hz) |
50 / 60 |
| Rated current (A) |
630 |
630 |
630 |
1,250 |
630 |
630 |
630 |
1,250 |
|
1,250 |
1,250 |
1,250 |
2,000 |
1,250 |
1,250 |
1,250 |
2,000 |
|
|
2,000 |
2,000 |
2,500 |
|
2,000 |
2,000 |
2,500 |
|
|
|
2,500 |
3,150 |
|
2,500 |
2,500 |
3,150 |
|
|
|
3,150 |
4,000 |
|
|
3,150 |
4,000 |
|
|
|
4,000 |
|
|
|
4,000 |
|
| Rated short-circuit breaking current (kA) |
25 |
31.5 |
40 |
50 |
25 |
31.5 |
40 |
50 |
| Rated short-circuit making current (kA) |
65 |
82 |
104 |
130 |
65 |
82 |
104 |
130 |
| Short-time withstand current for 3sec (kA) |
25 |
31.5 |
40 |
50 |
25 |
31.5 |
40 |
50 |
| Power-frequency withstand voltage (kV, 1mim) |
20 |
28 / 42 |
| Impulse withstand voltage (kV, 1.2×50㎲) |
60 |
75 |
| Operating duty |
O - 0.3sec - CO - 3min - CO / CO - 15sec - CO |
| Closing time (ms, at DC110V) |
55 |
54 |
55 |
54 |
| Opening time (ms, at DC110V) |
32 |
36 |
32 |
36 |
| Breaking time (cycles) |
3 |
| Closing operation |
System |
Motor spring stored energy |
| Supply voltage (V) |
DC48, 110, 125, 220 / AC110, 125, 220 |
| Closing & tripping control |
Tripping system |
Shunt trip |
| Supply voltage (V) |
DC48, 110, 125, 220 / AC110, 125, 220 |
| Operating life (times) |
Mechanical operation |
30,000 |
| Auxiliary contacts |
4NO+4NC, 7NO+7NC (Max. 10NO+10NC+1W) |
| Weight (kg,
Main-body) |
110 |
110 |
115 |
200 |
110 |
110 |
115 |
200 |
|
110 |
110 |
115 |
|
110 |
110 |
115 |
|
|
|
130 |
130 |
250 |
|
130 |
130 |
250 |
|
|
|
200 |
250 |
|
|
200 |
250 |
|
|
|
200 |
250 |
|
|
200 |
250 |
|
|
|
250 |
|
|
|
250 |
|
|
|
Model |
HVF314 |
HVF315 |
HVF316 |
HVF611 |
HVF614 |
HVF714 |
HVF705 |
| Standard |
IEC 62271-100 |
| Rated voltage (kV) |
17.5 |
24 / 25.8 |
36 |
36 |
| Frequency (Hz) |
50 / 60 |
| Rated current (A) |
630 |
630 |
630 |
630 |
630 |
1,250 |
1,250 |
|
1,250 |
1,250 |
1,250 |
1,250 |
1,250 |
2,000 |
2,500 |
|
|
2,000 |
2,000 |
2,000 |
2,000 |
2,500 |
3,150 |
|
|
2,500 |
2,500 |
|
2,500 |
|
|
|
|
|
3,150 |
|
|
|
|
| Rated short-circuit breaking current (kA) |
25 |
31.5 |
40 |
12.5 |
25 |
25 |
31.5 |
| Rated short-circuit making current (kA) |
65 |
82 |
104 |
32.5 |
65 |
65 |
82 |
| Short-time withstand current for 3sec (kA) |
25 |
31.5 |
40 |
12.5 |
25 |
25 |
31.5 |
| Power-frequency withstand voltage (kV, 1mim) |
38 |
50 / 65 |
70 |
70 |
| Impulse withstand voltage (kV, 1.2×50㎲) |
95 |
125 |
170 |
170 |
| Operating duty |
O - 0.3sec - CO - 3min - CO / CO - 15sec - CO |
| Closing time (ms, at DC110V) |
52 |
68 |
75 |
62 |
| Opening time (ms, at DC110V) |
32 |
45 |
42 |
| Breaking time (cycles) |
3 |
5 |
5 |
| Closing operation |
System |
Motor spring stored energy |
| Supply voltage (V) |
DC48, 110, 125 / AC110, 125, 220 |
| Closing & tripping control |
Tripping system |
Shunt trip |
| Supply voltage (V) |
DC48, 110, 125, 220 / AC110, 125, 220 |
| Operating life (times) |
Mechanical operation |
30,000 |
20,000 |
| Auxiliary contacts |
4NO+4NC, 7NO+7NC (Max. 10NO+10NC+1W) |
| Weight (kg,
Main-body) |
110 |
110 |
115 |
110 |
110 |
130 |
340 |
|
110 |
110 |
115 |
110 |
130 |
145 |
400 |
|
|
130 |
130 |
|
145 |
180 |
400 |
|
|
|
200 |
|
|
|
|
|
|
|
200 |
|
|
|
|
|
HVF Vacuum Circuit Breaker
(VCB) Order Information
- Selection table for rating, pole distance
and mounting
- Standard:
IEC62271-100
|
Specification |
Model |
Order
code |
Applicable mounting |
|
Rated
voltage
(kV)
|
Rated breaking
current (kV)
|
Rated
current
(kV)
|
Pole distance of
VCB body (mm)
|
Fixed
type |
Draw-out type cradle |
|
7.2
|
25 |
630 |
150 |
HVF1141 |
HVF1141 C |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
1,250 |
150 |
HVF1142 |
HVF1142 C |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
31.5 |
630 |
165 |
HVF1151 |
HVF1151 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
1,250 |
165 |
HVF1152 |
HVF1152 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,000 |
165 |
HVF1154 |
HVF1154 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
40 |
630 |
165 |
HVF1161 |
HVF1161 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
1,250 |
165 |
HVF1162 |
HVF1162 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,000 |
165 |
HVF1164 |
HVF1164 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,500 |
210 |
HVF1166 |
HVF1166 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
3,150 |
210 |
HVF1167 |
HVF1167 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
4,000 |
275 |
HVF1168 |
HVF1168 I |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
50 |
1,250 |
210 |
HVF1172 |
HVF1172 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,000 |
275 |
HVF1174 |
HVF1174 I |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,500 |
275 |
HVF1176 |
HVF1176 I |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
3,150 |
275 |
HVF1177 |
HVF1177 I |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
4,000 |
275 |
HVF1178 |
HVF1178 I |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
12 |
25 |
630 |
150 |
HVF2141 |
HVF2141 C |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
1,250 |
150 |
HVF2142 |
HVF2142 C |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
31.5 |
630 |
165 |
HVF2151 |
HVF2151 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
1,250 |
165 |
HVF2152 |
HVF2152 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,000 |
165 |
HVF2154 |
HVF2154 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,500 |
210 |
HVF2156 |
HVF2156 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
40 |
630 |
165 |
HVF2161 |
HVF2161 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
1,250 |
165 |
HVF2162 |
HVF2162 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,000 |
165 |
HVF2164 |
HVF2164 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,500 |
210 |
HVF2166 |
HVF2166 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
3,150 |
210 |
HVF2167 |
HVF2167 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
4,000 |
275 |
HVF2168 |
HVF2168 I |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
50 |
1,250 |
210 |
HVF2172 |
HVF2172 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,000 |
275 |
HVF2174 |
HVF2174 I |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,500 |
275 |
HVF2176 |
HVF2176 I |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
3,150 |
275 |
HVF2177 |
HVF2177 I |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
4,000 |
275 |
HVF2178 |
HVF2178 I |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
17.5 |
25 |
630 |
150 |
HVF3141 |
HVF3141 C |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
1,250 |
150 |
HVF3142 |
HVF3142 C |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
31.5 |
630 |
165 |
HVF3151 |
HVF3151 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
1,250 |
165 |
HVF3152 |
HVF3152 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,000 |
165 |
HVF3154 |
HVF3154 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,500 |
210 |
HVF3156 |
HVF3156 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
40 |
630 |
165 |
HVF3161 |
HVF3161 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
1,250 |
165 |
HVF3162 |
HVF3162 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,000 |
165 |
HVF3164 |
HVF3164 D |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,500 |
210 |
HVF3166 |
HVF3166 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
3,150 |
210 |
HVF3167 |
HVF3167 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
24 |
12.5 |
630 |
210 |
HVF6111 |
HVF6111 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
1,250 |
210 |
HVF6112 |
HVF6112 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,000 |
210 |
HVF6114 |
HVF6114 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
25 |
630 |
210 |
HVF6141 |
HVF6141 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
1,250 |
210 |
HVF6142 |
HVF6142 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,000 |
210 |
HVF6144 |
HVF6144 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
2,500 |
210 |
HVF6146 |
HVF6146 F |
XA |
EA, ES, FA, FS, SF |
GA, GS |
GE |
|
36 |
25 |
1,250 |
275 |
HVF7142 |
HVF7142 I |
XA |
EA, ES, FA, FS |
GA, GS |
GE |
|
2,000 |
275 |
HVF7144 |
HVF7144 I |
XA |
EA, ES, FA, FS |
GA, GS |
GE |
|
2,500 |
275 |
HVF7146 |
HVF7146 I |
XA |
EA, ES, FA, FS |
GA, GS |
GE |
|
31.5 |
1,250 |
275 |
HVF7052 |
HVF7052 I |
XA |
EA, ES, FA, FS |
GA, GS |
GE |
|
2,500 |
275 |
HVF7056 |
HVF7056 I |
XA |
EA, ES, FA, FS |
GA, GS |
GE |
|
3,150 |
275 |
HVF7057 |
HVF7057 I |
XA |
EA, ES, FA, FS |
GA, GS |
GE |
|
Mounting |
Code |
Structure |
| Fixed type |
XA |
Body |
| Draw-out
type |
EA |
Body part of ES cradle |
|
ES |
ES cradle (without shutter) |
|
FA |
Body part of FS cradle |
|
FS |
FS cradle (nonmetallic partition with shutter) |
|
SA |
Body part of SF cradle |
|
SF |
FS cradle (nonmetallic partition with shutter)
with screw type draw-in/out mechanism) |
|
GA |
Body part of GS cradle |
|
GS |
GS cradle (metallic partition with shutter and bushing) |
|
GE |
GS cradle with earthing switch |
|
|
|
