HYUNDAI
UAG UCG Earth
Leakage Circuit Breaker (ELCB)
|
Model |
Type |
Pole |
Breaking
Capacity [Icu]
(kA rms) |
Rated Current
(A) |
|
AC220V |
AC380V |
AC460V |
|
UAG100C |
Economy
|
2, 3 |
25 |
14 |
10 |
60, 75, 100 |
|
UCG250R |
2, 3 |
35 |
18 |
18 |
125, 150, 175, 200, 225 |
|
UCG400R |
3 |
35 |
30 |
25 |
250, 300, 350, 400 |
|
UCG630R |
3 |
50 |
45 |
35 |
500, 600 |
|
UCG800R |
3 |
50 |
45 |
35 |
700, 800 |
|
UAG30C |
Standard
|
2, 3 |
10 |
7.5 |
5 |
5, 10, 15, 20, 30 |
|
UAG50R |
2, 3 |
25 |
14 |
10 |
5, 10, 15, 20, 30, 40, 50 |
|
4 |
25 |
14 |
10 |
15, 20, 30, 40, 50 |
|
UAG60R |
3 |
25 |
14 |
10 |
60 |
|
UCG100R |
2, 3, 4 |
50 |
30 |
25 |
15, 20, 30, 40, 50, 60, 75, 100 |
|
UCG250S |
3, 4 |
50 |
25 |
25 |
125, 150, 175, 200, 225 |
|
UCG400S |
3 |
50 |
42 |
35 |
250, 300, 350, 400 |
|
UCG630S |
3 |
100 |
65 |
50 |
500, 600 |
|
UCG800S |
3 |
100 |
65 |
50 |
700, 800 |
|
UAG30R |
High
Breaking Capacity
|
3 |
25 |
14 |
10 |
5, 10, 15, 20, 30 |
|
UCG50R |
3 |
50 |
25 |
25 |
15, 20, 30, 40, 50 |
|
UCG50S |
4 |
65 |
35 |
35 |
15, 20, 30, 40, 50 |
|
UCG100S |
3, 4 |
65 |
35 |
35 |
15, 20, 30, 40, 50, 60, 75, 100 |
|
UCG250N |
3, 4 |
65 |
35 |
35 |
125, 150, 175, 200, 225 |
|
UCG400H |
3 |
85 |
65 |
50 |
250, 300, 350, 400 |
|
UCG400L |
Current
Limiting |
3 |
125 |
100 |
85 |
250, 300, 350, 400 |
|
UCG630L |
3 |
125 |
100 |
85 |
500, 600 |
|
UCG800L |
3 |
125 |
100 |
85 |
700, 800 |
|
