| General
Specifications |
| Construction |
Panel flush mounting |
| Connection |
Screw terminals |
| Housing
material |
Plastic(resin) light-gray |
| Input
configuration |
Differential Input |
| Scaling |
Functional switches at the front panel |
| |
| Display |
| LED |
0.6 inch or 1 inch 7-segment, red or green |
| Number of display
digits |
4(-9999 ~ 9999) |
| Decimal point
position |
3 positions
selected by a programmed functional switches at
the front panel |
| Set-point
adjustments |
Front-accessed programmed functional switches |
| Hysteresis
(dead-band) |
0.1~2.0% of FS by programmed functional switches |
| Over-range
indication |
Display "OVEr" |
| Engineering unit
indication |
Sticker attached |
| Burn
Out |
Selectable Up-Scale or Down-Scale |
| |
| Installation |
| Power
Supply |
AC 110V/220V, 50/60Hz |
| DC 24V ±10%,
5VA |
| Operating
temperature |
0 to 55°C
(32 to 131°F) |
| Operating
humidity |
20-80% RH (Non-condensing) |
| Mounting |
Panel flush mounting |
| Size |
W96 x H48 x D118mm (3.78"
x 1.89" x 4.65") |
| |
| Performance |
| Accuracy |
±0.1% of FS |
| Temperature
coefficient |
±0.01% of FS +
0.1 digit / °C |
| Insulation
resistance |
100MΩ or more with 500VDC |
| Dielectric
strength |
AC1500V at 1 Minute
(input to power) |
|
|
| Input
|
|
DC
voltage
0
~ 300VDC, minimum
span: 10mV
|
|
Input
|
Impedance
|
|
0
- 10
mV
|
10
KΩ
or more
|
|
0
- 100
mV
|
100
KΩ
or more
|
|
0
- 10
V
|
1
MΩ
or more
|
|
>
12 V
|
2.5
KΩ
/ V
|
|
|
DC
current
Resister
incorporated
|
|
Input
|
Resistance
|
|
4
- 20
mA
|
250
Ω
|
|
10
- 50
mA
|
100
Ω
|
|
0
- 1
mA
|
1000
Ω
|
|
|
PMC
|
Input:
100~100KΩ
|
|
RTD
|
Input:
-200~+600°C
|
|
|
|
|
Output
|
|
DC
current
|
|
Output
|
Load
Resistance
|
Impedance
|
|
4
- 20
mA
|
0
- 500
Ω
|
5
MΩ
or more
|
|
0
- 20
mA
|
|
0
- 10
mA
|
0
- 1000
Ω
|
|
0
- 1
mA
|
0
- 10
KΩ
|
|
|
DC
voltage
|
|
Output
|
Load
Resistance
|
Impedance
|
|
0
- 10
mV
|
10
KΩ
or more
|
10
Ω or
less
|
|
0
- 100
mV
|
100
KΩ
or more
|
100
Ω or
less
|
|
1
- 5
V
|
1
KΩ or
more
|
0.1
Ω or
less
|
|
0
- 10
V
|
10
KΩ or
more
|
|
|
|
|
|
Relay
Output
|
|
Rating
|
30VDC
at 1A or 250VAC at 0.2A (Resistive
Load)
|
|
|
|
| Ordering
Information |
| Specify code number and
variables |
| Code
number |
S-CON 200-Input, Output, Power (e.g S-CON 200-DNX) |
| Special input,
outputs
range |
Code,
Display range, Input range, Output range
(e.g
S-CON 200-DNX, 0-9999, 4-20mA, 4-Alarm)
|
|
